Specifications
Please note - specifications subject to change without prior notice.
| FRAME | All New Series 4 6061 Aluminum, 29” Wheels, 160mm Travel MultiTrac LT Suspension Platform, Integrated Downtube Storage, Adjustable Headset & CS Length/BB Height, Boost Thru- Axle, 73mm Threaded BB w |
| FRONT SUSPENSION | RockShox Zeb Ultimate, 170mm Travel, 29", 110x15mm Maxle Stealth, 44mm Offset |
| REAR SUSPENSION | RockShox Super Deluxe Coil Ultimate, 205x65, 30xM8 Lower Hardware, Custom Tune, Spring Rates S/M: 350lbs, L/XL:400lbs |
| RIM | Marin, Double Wall Alloy, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible |
| HUB REAR | Formula, DCL-3482, 148x12, 4 Sealed Bearings, 6-Bolt Disc, XD Driver, 32H |
| HUB FRONT | Formula, DC-711, 110x15mm, 6-Bolt Disc, 32h |
| SPOKES | 14g Black Stainless Steel |
| TIRES | Maxxis Assegai MAXX GRIP, Front 29x2.5 EXO , Rear 27.5x2.5" DoubleDown, Tubeless compatible |
| DERAILLEUR REAR | SRAM GX Eagle AXS T-Type |
| DERAILLEUR FRONT | - |
| SHIFT LEVER | SRAM AXS POD MMX |
| CRANKSET | SRAM GX Eagle, 32T, 55MM CL, 170MM Length |
| BOTTOM BRACKET | SRAM DUB MTB 73 |
| CHAIN | SRAM GX Eagle T-Type |
| CASSETTE | SRAM GX 1275 T-Type 10-52T |
| BRAKES FRONT | SRAM Code Bronze 4-Piston Hydraulic Disc, HSC 200mm Rotor |
| BRAKES REAR | SRAM Code Bronze 4-Piston Hydraulic, HSC 200mm Rotor |
| BRAKE LEVERS | SRAM Code Bronze Stealth Hydraulic |
| HANDLEBAR | Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back |
| STEM | Marin CNC, 35mm Length, 35mm Bar Bore |
| GRIPS | Marin Grizzly Lock-On |
| HEADSET | FSA Custom, Adjustable HTA Design |
| SEATPOST | TranzX, YSP39 1x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm |
| SADDLE | Marin Speed Concept |
| PEDALS | - |
| EXTRAS | Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head |
| EXTRAS | Downtube Storage Bag |
