Specifications
Please note - specifications subject to change without prior notice.
| FORK | Fox 38 Performance Elite eMTB , Air, 170mm suspension travel, Tapered, 44mm fork offset, 29x2.6" max wheelsize |
| SHOCK | Fox Float X Performance |
| BRAKES | Shimano XT |
| ROTORS | Shimano RT64 / Shimano RTEM600 FR 220 mm, RR 203 mm |
| HEADSET | Acros ICR MERIDA INTEGRATED neck w/ Blocklock |
| HANDLEBAR | MERIDA EXPERT eTR |
| HANDLEBAR STEM | MERIDA EXPERT eTR II |
| GRIP | MERIDA EXPERT EC |
| DERAILLEUR (R) | Shimano XT RDM8130 LinkGlide 11 |
| SHIFTERS | Shimano SL -MT500-IL / Shimano XT M8130 11 |
| SEAT POST | MERIDA TEAM TR II, 34.9mm diameter, 0mm setback, XSHORT 30-200mm travel seatpost, SHORT, MID, LONG and XLONG 30-230mm travel seatpost |
| SEAT CLAMP | MERIDA EXPERT |
| SADDLE | Proxim Nembo Steel |
| PEDAL | VP VP-532 |
| CHAIN | CNLG500 |
| CHAINWHEEL | FSA 1x Steel Chainring, 36 teeth |
| CRANK | Shimano FC-E8150, 165 mm all sizes |
| FREEWHEEL | Shimano LG700, 11-50 teeth, 11 speed |
| HUBS | Shimano XT |
| RIM | MERIDA EXPERT TR II, 28mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included), front 29", rear 27.5" |
| TYRE FRONT | Maxxis Assegai, 29x2.5 ", fold, TR EXO 3C MaxxGrip |
| TYRE REAR | Maxxis Minion DHR II, 27.5x2.4 ", fold, 3C DD TR MaxxTerra |
| AXLES | MERIDA EXPERT TR, including removeable lever, 6/4mm allen key |
| SPOKES | Black stainless |
| LIGHT FRONT | Lezyne Hecto StVZO E350 Reverse |
| LIGHT REAR | USB REAR Light CG-214RG |
| DRIVE UNIT | Shimano EP801 |
| BATTERY | Trendpower Internal Battery 600 Wh TPS-C15-58SD, Shimano Gen 2 integrated |
| DISPLAY | Shimano SC-EM800 |
